Chapter 74-20-00 : Double Ignition Coil Assy., SMD-Electronic Module

See product table below

These illustrations and parts listings serve only as a guide, the selection of complex parts should be done by an approved iRMT to ensure that the correct parts are ordered. All maintenance and repairs should be carried by an appropriately rated iRMT. Comet Aviation Supplies will not be held responsible for parts incorrectly supplied. Refer to www.flyrotax.com and www.rotaxirmt.com for further information.

*Please select the correct version for your engine.

*Please pay attention to the footnotes as designated by an alphabet in the columns below.

*Please contact us directly to order parts for a Rotax certified engine.

*PPE – Parts Per Engine ; AR – As Required

*Please note that the price of PRE-ORDER items are subject to change due to fluctuating exchange rates. A sales representative will get back to you with an updated quote.

a. In a roll, Ignition cable 620 mm;

b. In a roll, Protection hose 560 mm

c. In a roll, Protection hose 500 mm

d. In a roll, Protection hose 450 mm

e. Not necessary at intake manifold part no. 867688;

f. Marked with S/N;

  • Introduced as per S/N as follows:
  • 04.0388 with altered insulation only for spare parts



g. for crankcase part no. 886354, part no. 886358 and older;

h. At crankcase part no. 888364 or newer crankcase;

i. Not suitable for intake manifold part no. 867688;

j. Necessary at version with ring mount;

k. In a roll

l. Use part no. 842742 and 953390 only together;

m. SI-912-013 / SI-914-016 current issue

  • See Maintenance Manual Heavy of the respective engine type, current issue.



n. In a roll, silicone hose 120 mm

o. SI-912-020 / SI-914-022 current issue

p. 1x lock washer A6 part no. 945751 is not needed after production-year 2010 on position between the bracket 2 part no. 851267 and the hex. nut M6.

q. Without magneto wheel consisting of 20, 21, 22, 23, 44, 46

r. Required for the following cylinders: 413235 / 413236 / 413245 / 413246 / 413185 / 413195. Danger of abrasion!

s. Short lines connected with 965359 and 965446. Lenght = 85 mm (instead of 70 mm).
